| ITEM |
| 1、High
glossy |
|
| 2、Common
glossy |
|
| 3、Low
glossy |
|
| 4、Vein |
|
| 5、Hybrid
impact |
|
| 6、Metal
powder coating |
|
| |
|
| CHARACTERISTIC |
| 1、Superior
resistance to chemicals |
| 2、Superior
insulation |
|
| 3、Corrosion
protection |
|
| 4、High
hardness |
|
| 5、Superior
in mechanical |
|
| |
|
| TECHNICAL
PROPERTY OF COATING |
| Examined
material |
cold
rolled steel-plate |
|
| Pre-treatment
|
zinc-parkerization
|
|
| Testing
item |
testing
method |
result |
| Outlook
- |
eyeballing |
smooth |
| Coating-thickness |
thickness
indicator(um) |
60-80 |
| Cure
condition |
thermostat
|
190℃×20min |
| Glossiness |
mirror
reflectivity 6 |
≤15 |
| Impact
strength |
hammer
50kg.com |
≥50 |
| Pliability
test |
180°pliability
|
2mm |
| Adhesion
force |
1mm×1mm×100 |
100% |
| surface
strength |
lead
strength |
≥2H |
| Salt
spray test |
400h |
≤2mm |
| Resistance
to humid |
400h
|
good |
| Resistance
to acid |
5%HCL，240h
|
good |
| Resistance
to aldali |
5%NaOH,240h |
good |
| |
| PURPOSE |
| 1、metal
furniture used indoors |
|
| 2、storage
shelf |
|
|
| 3、auto-parts |
|
|
| 4、metal
toy |
|
|
| 5、water
valve |
|
|
| 6、electric
insulated parts |
|
| 7、home
metal electric appliance shell |
|
| 8、others |
|
|
| |
|
|
|
|
|
